NFC9280 LED pan-light light

The shell uses light alloy materials and is high-tech spraying treatment, abrasion resistance, anti-corruption, waterproof and dust-proof; transparent parts use tempered high borosilized glass, high light transmission rate, good impact resistance, can make the lamps in various harsh ones in various harsh onesNormal work in the environment;

Product Documentation

Scope

In order to meet metallurgical, railways,tunnel,The needs of flammable and explosive fields such as power plants and ships, and develop and produceNFC9280LEDGlowlamp.Widely applicable to various factory areas, workshops, stations, large facilities and equipment areas to do fixed lighting

Features

Adopt international brandsLED light sourceHigh emotional efficiency, high life spanMore than 50,000 hours.

LED pan-light festivalCan be low-consumption, consumption is only the same light flux incandescent lamp20%

The light is soft, no glare, and it will not cause the fatigue of the operators' eyes and improve work efficiency;

The shell is selected from light alloy materials and performs high-tech spraying treatment, abrasion-resistant, anti-corruption, waterproof and dust-proof;

The transparent parts adopt temperament of tensile highbbao silicon glass, with high light transmission and good impact resistance, which can make the lamps work properly in various harsh environments;

The LED pan-light light has a variety of installation methods such as top-absorbing, wall-mounted, and boom-type to meet the lighting needs of different on-site environments.

Technical parameter

name    say

LED pan-light light

Light    source

LED

Rated power

Standard100W (optional 120W, 150W)

Input voltage

AC220V (optional AC/DC12-36V)

Protection level

IP67

Anticorrosive grade

WF2

Introduce cable

Φ8-Φ10mm

Ambient temperature

-20~+40

Life

100000h

Appearance

Φ300×220mm

Heavy    quantity

6.8KG

Light curve
Installation size
